Euromax 30

Small scale automated production line for back-contact PV-modules

Panels PH: 30
MW/YEAR: 86
Workers per shift: 2
Printing cell interconnection
Upwards elevator
Back sheet lay-up
Downwards elevator
Flipping
Pre-tagging
Glass de-stacking
Front encapsulant unwinding and lay-up
Quality inspection
Cell positioning
Lay-up of rear perforated insulator
Euromax 30
Explore Euromax 30
Explore the Euromax 30
Close overview

Euromax 30

Small-scale automated production line for back-contact PV modules fully equipped and provided with high-tech equipment. Customized to your specific needs and facility layout and made to be controlled by just a few operators per shift.

Highest standard in PV-modules

Designed
to perform

We incorporate advanced automation, robotics and the latest innovation in solar technology to produce the highest standard in PV modules. Premium PV modules of the highest quality with the latest defect rates in the industry.

Fully compatible with:

Cell Cuts
Full and half-cut cells

Panel dimensions
Max. panel size
2,400 x 1,400 mm

Cell types
All back-contact cells
(MWT, IBC, HJ-BC)

Cell dimensions
⁠Cell dimensions at
customer choice

Play
Main features

The superiority of the Euromax 30



Innovative cell positioning

Innovative cell positioning

Unpilling and placing solar cells is a sensitive process. Eurotron automation distinguishes itself by showing close-to-zero yield losses. How is that possible: first of all by using a special developed ultrasoft gripper system, based on multiple Bernoulli combinations. By this gripper, the cells are picked up, pass a vision inspection and quality control system which is provided with dedicated and smart algorithms. During advancing to the placing position, the cell gripper receives correction information with respect to X, Y and Theda direction, in order to place the cell at its perfect position, allowing an optimal electrical contact as well as the best optical appearance for optical alignment. Cells which are out of specs can be discarded even before placing. The beauty of this system is ONE-TIME cell contact which boosts the reliability of placing and reduces cell breakage.

Read more

SolarVision
system

The SolarVision system is one of the key functions in our turnkey production lines. Through the SolarVision system, we guarantee the highest quality solar panels built exactly as designed.

Laser cutting unit
Interconnenction

Cutting-edge technology for applying interconnection

The interconnection unit is a high-capacity printing unit which applies solder paste or conductive adhesive on the contact areas of the backsheet foil.

Works with module sizes up to 2,400 x 1,400 mm

On the Euromax 90, both small PV modules and PV modules with sizes up to 2,400 x 1,400 mm can be produced fully automatically. Our advanced technology and latest innovation in solar technology ensures the most reliable and high-quality PV modules with the lowest defect rates in the industry.

Module Sizes

Integrated quality inspection

It's important to know whether a PV module meets the strict quality requirements. Therefore, each PV module is assessed for the presence and placement of cells using our smart vision system.

Integrated quality inspection
Module Sizes

30 PV modules per hour

The Euromax 30 is a small scale automated front-end production line with an output of 30 back-contact PV modules per hour. On an annual basis, 86 MWp of total capacity can be produced.
